No electric shock risk, making it safe and reliable
Automatically flips to a certain angle during the rainy season
No personnel are required for monitoring
once installed, pedestrians and vehicles can pass normally
1. Product Overview
The Hydraulic Floating Barrier is a water-driven flood control device that automatically opens using the buoyancy of water. The barrier consists of a ground frame, a floating flip barrier, a waterproof rubber soft board, and embedded parts. In the dry season, the barrier is embedded in the ground frame; during the rainy season,when the barrier comes into contact with water, it floats and automatically flips to a certain angle. As the water level rises, it eventually flips into an upright position, blocking the floodwater.
2. Applicable Locations
It is suitable for civil defense areas, underground parking lots, subway station entrances and exits, tunnel entrances and exits, and other similar locations.
3. Features
● The flood control process does not require electrical power, ensuring there is no electric shock risk, making it safe and reliable.
● Driven by water buoyancy, small water flows will not cause the barrier to rise automatically. No personnel are required for monitoring,and once installed, pedestrians and vehicles can pass normally.
● Pedestrian entrances use light-duty specifications with aluminum alloy panels, vehicles entrances use heavy-duty specifications with stainless steel panels,featuring anti-slip and protective measures on the surface. The interior of the Hydraulic Floating Barrier uses polyurethane foam, and the ground frame is made of stainless steel.
● Modular design allows the barriers to be assembled to fit any gate opening width.The maximum width of a single barrier is limited to 10 meters. The barrier comes in standard heights of 600mm, 800mm, 1000mm, and 1200mm(custom sizes available).
● It offers both embedded and surface-mounted installation options. When installed in the embedded mode, drainage pipes should be set at the bottom of the trench. During the dry season, the barriers can support the passage of medium-sized vehicles.
